SPECIFICATION
| GENERAL SPECIFICATION |
| DIMENSIONS AND WEIGHT |
• L x W x H : 370 x 290 x180 mm
• Net weight : 3.5 kg
|
| TEST TYPES |
Tympanometry, Reflex, Decay, ARLT, Quick test, Pure tone test, Speech test, ABLB, Tone Decay, Stenger,
Autothreshold, Bekesy
|
| DISPLAY |
• 7” TFT Color display |
| PRINTER |
• Built-in fast thermal printer with paper width: 112 mm supplied as standard part
|
| POWER SUPPLY |
• 220V AC/60 Hz/40VA |
| AUDIOMETRY OPERATING SPECIFICATIONS |
| RANGE |
• Frequency range :
125 - 8000 Hz (with DD45)
250 - 6000 Hz (with B71)
• Range stimuli level -10 up to 120 dB HL
|
| ACCURACY |
Frequency ± 1%
|
| TYPE OF SIGNALS |
• Pure tone
• Warble
• Narrow band noise
• Speech noise
• White noise
• External signal
• External mike
• Speech material recorded on SD card
|
| OUTPUT TRANSDUCERS |
• ACR, ACL
• BC
• Free field
|
| TYMPANOMETRY OPERATING SPECIFICATIONS |
| INTENSITY |
• probe tone frequency : 226 Hz ±1%
• probe tone intensity : 85dB SPL ±1dB
|
| AIR PRESSURE |
• Control : Automatic
• pressure range: +400daPa / –600daPa adjustable in 50daPa steps
• pump speed: 50, 100, 200, 300 daPa/s and auto
|
FREQUENCIES AND
INTENSITY RANGES |
Ipsi :
• Maximum Pure tone level range: 110 dB HL
• Maximum Noise level range: 100 dB SPL
• Minimum/Maximum Frequency: 250/4000 Hz
• Noise: BBN, HPN, LPN
• Frequency accuracy: ±1%
Contra :
• Maximum Pure tone level range: 120 dB HL
• Maximum Noise level range: 115 dB SPL
• Minimum/Maximum Frequency: 250/8000 Hz
• Noise: BBN, HPN, LPN
• Frequency accuracy: ±1%
|
