SPECIFICATION
| GENERAL SPECIFICATION |
| DIMENSIONS AND WEIGHT |
• L x W x H : 370 x 290 x180 mm
• Net weight : 3.5 kg
|
| TEST TYPES |
Tympanometry, Reflex, Decay, Quick Check, Quick Screening
|
| DISPLAY |
• 7” TFT Color display |
| PRINTER |
• Built-in fast thermal printer with paper width: 112 mm supplied as standard part
|
| POWER SUPPLY |
• 220V AC/60 Hz/40VA |
| TYMPANOMETRY OPERATING SPECIFICATIONS |
| INTENSITY |
• probe tone frequency: 226 Hz ±1%
• probe tone intensity: 85dB SPL ±1dB
|
| AIR PRESSURE |
• Control: Automatic
• pressure range: +400daPa / –600daPa adjustable in 50daPa steps
• pump speed: 50, 100, 200, 300 daPa/s and auto
|
FREQUENCIES AND
INTENSITY RANGES |
Ipsi :
• Maximum Pure tone level range: 110 dB HL
• Maximum Noise level range: 100 dB SPL
• Minimum/Maximum Frequency: 250/4000 Hz
• Noise : BBN, HPN, LPN
• Frequency accuracy : ±1%
Contra :
• Maximum Pure tone level range: 120 dB HL
• Maximum Noise level range: 115 dB SPL
• Minimum/Maximum Frequency: 250/8000 Hz
• Noise : BBN, HPN, LPN
• Frequency accuracy: ±1%
|
※ 이 제품은 "의료기기" 이며 "사용상의 주의사항" 과 "사용방법" 을 잘 읽고 사용하십시오.
(광고심의필 : 심의번호 2019-I10-19-1443)
청각전문가의 체계적인 장비 교육
